Digital Height Gages – Accurate and Effortless Measurement Tools
Digital height gages are advanced measuring tools used for accurately determining the height of components, offering easy-to-read digital displays for efficient measurements. Used in a wide range of industries such as manufacturing, automotive, aerospace, and metalworking, digital height gages simplify the measurement of components, tool setups, and layout markings on workpieces.
These modern tools combine the convenience of digital displays with the precision of high-resolution encoders, offering fast, consistent, and easy-to-read measurements on shop floors and in quality control labs.
Key Features to Look For in Digital Height Gages
Clear Digital Display
Offers excellent readability for precise height measurements.
Wide Measurement Range
Supports a broad torque range suitable for various industrial applications.
Multiple Units
Switch easily between mm and inches for flexibility.
Zero Setting Function
Quickly set a new reference point at any height.
Applications of Digital Height Gages
- Part Height & Step Measurement: Used to measure component heights and step depths with precision.
- Layout Marking: Ideal for scribing accurate reference lines on workpieces.
- Tool Height Setting: Assists in setting accurate tool heights on CNC machines.
- Dimensional Tolerance Checking: Verifies if parts meet design tolerances during inspection.
- Reference Comparison: Compares part dimensions against standards or master references.
How to Use Digital Height Gages
- Power On & Zero: Turn on and set a reference point.
- Adjust Measuring Head: Slide/fine-tune the head to touch the part.
- Read the Display: Instantly see the measured height on the LCD.
- Record or Export: Save or transmit the data via USB or Bluetooth (if available).
Typical Specifications (Sample Model)
| Specification | Value |
|---|---|
| Measuring Range | 0 – 600 mm |
| Resolution | 0.001 mm |
| Accuracy | ±0.02 mm |
| Display | LCD (Backlit Optional) |
| Units | mm/inch selectable |
| Output | USB, RS-232, Bluetooth |
| Material | Stainless steel + granite base |
